Step 4 – Turtle challenge 2.3
Not every flag is just made up of stripes like the Lithuanian flag or the French tricolour.
Some flags are a little trickier to draw.
Problem – the flag of Benin
The flag of Benin has a vertical stripe and then two horizontal strikes.
That makes it a bit harder to draw. Until you work out a shortcut...
The basic colours here are probably:
- the left bar is "darkgreen"
- the top section is "gold"
- the bottom setion is "red"
Remember, the base flag is 180 steps wide and 120 steps tall.
I'm sure you could give this a go knowing what you already do.
- Write code to draw the flag of Benin
Use the notes above and what you already know to help
- Run your code to test it out
- If it's not quite right the first time, make some changes until you get it right.
Did you manage it?
Benin is a country in West Africa. It's west of Nigeria on the coast. It used to be part of the French colonial empire and became independent in 1960.
Shortcut method
There's a shortcut method here that would probably make the code quicker. You might have already figured it out.
Try this sequence:
- Draw a flag like the Ukrainian flag, using a gold and red section
Each stripe with be 180 steps wide (the full width of the flag) and 60 steps tall (half the height)
- Change the colour to darkgreen
- Draw a dark green shape about 60 steps wide over the top of part of the first flag you drew
You'll need to be a bit clever when you draw the green section. It will depend on where your turtle finished up with the yellow and red stripes
You'll notice that this code doesn't produce a perfect flag. The green bar wants to be a little bit wider and you might have a small red line at the bottom. To get rid of the red line, just add code to end up back in the bottom left corner.
